Improved handling of alternate dimensions (for example inch dimensions) in material reports. Reporting from Containment Browser to generate easily 3D space based material take-offs.Ĭomparison of cable ways and nodal networks to find easily for example latest changes which can affect to cable routes. Non-watertight multi-pipe penetrations - Common Sleeves. Greatly improved Hole Management especially to handle cases where hull plates are modified after hole requests are generated. Some shared settings of PLANT MODELLER were modifiable by regular user.Īutomated publish of documents to eSHARE. New mm based tags were created: Surface area mm2 PI_TAG_SURFACE_AREA_MM (.iu) and Internal Volume mm3 PI_TAG_INTERNAL_VOLUME_MM (.iV). In earlier versions also alternate formats of key dimensions were protected.īug fixes: - It was not possible to convert Surface area and internal volume using normal conversionĬodes. Possibility to add and change alternate format of key dimensions in dimension table. Alternate values are now available via tags $01, $02, etc. Values of dimensions are available as tags D01, D02, etc.
Nupas cadmatic Offline#
In offline replication, files of removed objects prevented replication.Īlternate dimensions are now available for reports the same way as primary dimensions.
Nupas cadmatic password#
When using COS accounts, system didnt remember password even if Remember Document replication failed in offline replication if file was modified on master serverĪfter it was requested to replica. Optimized use of already-read COS object information to improve performance of object browser for example when showing Part Sizes.īug fixes: - Empty document folders caused troubles when restoring backup.
Outfitting will not work with older Hull versions and Hull will not work with older Outfitting versions.Įbm files published with 2015Q3 PLANT MODELLER are compatible with 2015Q1 or newer eBROWSER. NUPAS-CADMATIC OUTFITTING 2015Q3 is compatible only with Nupas-CADMATIC HULL version 2015Q3 and newer.
Nupas cadmatic license#
License server of release 2015Q3 can be used for applications of versions 5.0 and newer. License server of release 2015Q3 is compatible only with license files for version 2015Q2 and it is not compatible with older license files. There are four releases annually and the release name refers to the year and the quarter when it has been published, e.g. The tools and features have been developed in close cooperation with our customers and stakeholders and represent further proof of CADMATICs commitment to continuously develop tools that enhance our customers operational efficiencies.ĬADMATIC continues the quarterly release model that was introduced last year. For Foran there should be a STEP import but we never have seen any results.Nupas-Cadmatic Outfitting Cadmatic Plant Design eShare Information Managementġ. To import 3D-models into Cadmatic you have to go the following way: Acis ( version 4.0 not higher) AutoCAD. Blohm+Voss and Lürssen is starting to use this software.
Nupas cadmatic software#
The absolutely high end software is Unigraphics. The reason is simpel SolidWorks is based on Parasolid but Dassault also owns the ACIS kernel. These formats could be served in the best way up to now by SolidWorks. The standard exchange formats are Parasolid (.x_t), ACIS (.sat) or STEP (.stp). Unigraphics and SolidWorks are Prarasolid based, Inventor, Mechanical_Desktop, AutoCAD and a lot of small CAD-Systems are based on ACIS. The international standard kernels are Parasolid or ACIS. Shipbuilding software normally has their origin in 2D (just to serve the cutting machines) and has poor geometrical kernel. Import and export of the solids is the most essential part. The suppliers are working with Unigraphics, Catia, ProE, SolidWorks, Inventor etc.
Shipbuilding is an assembly industry and you will need (and they will offer) 3D-models from sub suppliers. For the long run I wouldn’t use either Foran, Nupas-Cadmatic or Tribon-Equipment or any other shipbuilding specific software for machinery and outfitting.
